Lindy USB 3.2 Gigabit Ethernet Converter, Power Delivery

Note: Technology Products May Be Subject To Additional Fraud Checks By The Mega Team

The Lindy USB 3.2 Gen 1 Type C Gigabit Ethernet Converter with Power Delivery allows users to conveniently connect a computer, notebook or tablet to a Gigabit Ethernet network via a Type C USB port. The Converter provides USB 3.2 Gen 1 SuperSpeed data transfer rates up to 5Gbps so that the full bandwidth of the network can be used for a reliable and fast internet connectivity. PXE capability allows the computer to boot from a server on a network.

Ideal for ultrabooks or tablets which do not feature wired network connectivity, this converter is compact and lightweight making it convenient to carry around in a laptop or travel bag, allowing for wired network access from a wide range of devices. Power delivery from the USB port powers the converter so no power adapter is required for use. The converter features a USB Type C Power Delivery port which provides simultaneous charging of devices alongside network connectivity. It is also compatible with Thunderbolt 3 ports to allow use with a variety of modern tablets and laptops.

• Connects a USB 3.2 Type C computer to a Gigabit Ethernet network
• Supports 10/100/1000BASE-T, full and half duplex mode
• USB 3.2 / 3.1 Gen 1 / USB 3.0 SuperSpeed data transfer rates up to 5Gbps
• USB Type C Power Delivery port for charging a notebook/Macbook
• 2 year warranty

Information about USB 3.0, 3.1 & 3.2

• USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.
• USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps.
• USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.
• USB 3.2 Gen 2x2 supports data transfer rates up to 20 Gbps.

Package Contents

• USB 3.2 Type C Gigabit Ethernet Converter

TECHNICAL INFORMATION:

Specifications

• Interface: USB to RJ45
• Interface Standard: USB 3.2 / 3.1 Gen 1 / USB 3.0, Gigabit LAN
• Supported Bandwidth: 5Gbps (USB), 10/100/1000Mbps
• Chipset: VL102-Q4, RTL8153B, JW5017S
• Compatibility: USB Type C / Thunderbolt 3equipped computers (incl. Apple M1)
• Power Delivery: PD 3.0 up to 100W (20V 5A)
• Special Features: PXE (Preboot Execution Environment) support

Connectors

• Inputs: 1 x USB Type C (Male)
• Outputs: 1 x RJ45 (Female)
• Power: Bus-powered

Physical Properties

• Dimensions WxDxH:
  Housing: 30x54.8x15.2mm (1.18x2.16x0.6in)
  USB Connector: 12x21x6.6mm (0.47x0.83x0.26in)
• (Fixed) Cable Length: 170mm (6.69in)
• Housing Material: Plastic
• Net Weight: 0.026kg (0.06lb)
• Operating Temperature: -20°C - 40°C (-4°F - 104°F)
• Storage Temperature: -40°C - 80°C (-40°F - 176°F)
• Humidity: 10 - 70% RH (non-condensing)
• Colour: Black

Miscellaneous

• Packaging Type: Polybag
• Packaging Dimensions: 174x194mm (6.85x7.64in)
• Gross Weight: 0.036kg (0.08lb)
• Warranty (Years): 2
• Certificated: CE, FCC, RoHS & REACH, CP65

DOWNLOAD:

• User Manual for USB 3.2 Gen 1 Gigabit Ethernet Converter with PD
• Data Sheet for 43328 USB 3.2 Gen 1 Gigabit Ethernet Converter with PD
