Lindy HDMI & IR over IP Extender Kit

The Lindy HDMI & IR over IP Extender offers a reliable and cost-effective solution for extending HDMI signals over a local network setup. This versatile extender allows for point-to-point or larger-scale installations with the ability to expand using network switches and additional receivers, making it ideal for a variety of environments, from retail and office spaces to educational setups. The HDMI signal can be transmitted over long distances, with support for resolutions up to Full HD 1920x1080@60Hz, offering excellent content quality for digital signage and AV distribution needs.

Key Features

• Supports point-to-point or larger-scale HDMI signal distribution using a network setup
• Supports Full HD 1920x1080@60Hz resolution with 4:4:4 8bit color depth
• Supports up to 150m of transmission over Cat.6 cable, or even longer distances with additional network switches
• IR extension for simple control with included IR emitter and receiver cables
• HDMI loop-out port on the transmitter for local display connection
• Uses H.265 video compression for efficient bandwidth usage in larger installations
• 2-year warranty for added peace of mind

Applications

This HDMI & IR over IP Extender is perfect for:

• Retail environments requiring large-scale content distribution across multiple displays
• Residential installations for home AV distribution
• Hospitality setups such as hotels and restaurants with digital signage needs
• Connected office environments for distributing AV content across rooms or floors
• Educational setups requiring video and audio distribution in classrooms or lecture halls

Package Contents

• Transmitter Unit
• Receiver Unit
• IR Emitter Cable (1.5m)
• IR Receiver Cable (1.5m)
• Multi-country Power Supply (EU, UK, US & AUS)
• Lindy Manual

Technical Specifications

• AV Interface: HDMI
• Interface Standard: HDMI 1.3
• Supported Bandwidth: 6.75 Gbps
• Maximum Distance: 150m (492.12ft) via Cat.6 cable
• Maximum Resolution: 1920x1080@60Hz 4:4:4 8bit
• HDCP Support: 1.4
• EDID: Pass-through
• Audio Support: 2 Channel PCM
• IR Support: 20-60 kHz
• Transmission Protocol: IP (H.265 video compression)
• Transmission Medium: 1 x Cat.5e/6
• Chipset: SSC337DE - SSD203D
• Special Features: HDMI Loop Out port
• Connectors (Transmitter): HDMI (Female), RJ45 (Female), IR (Female)
• Connectors (Receiver): RJ45 (Female), IR (Female), HDMI (Female)
• Power: 5VDC 1A via 5.5/2.1mm DC socket
• Dimensions: 88x61.2x16.5mm (3.46x2.41x0.65in) per unit
• Housing Material: Metal
• Net Weight: 0.53kg (1.17lb)
• Operating Temperature: -10°C to 50°C (14°F to 122°F)
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Humidity: 20-90% RH (non-condensing)
• Colour: Black
• Certifications: CE, UKCA, FCC, RoHS, REACH, California Proposition 65

Download

• User Manual for HDMI & IR over IP Extender

Why Choose the Lindy HDMI & IR over IP Extender?

The Lindy HDMI & IR over IP Extender provides a flexible, scalable, and cost-effective solution for extending HDMI signals over long distances within a networked environment. It is perfect for expanding AV distribution across multiple locations, whether in retail, education, or home AV systems. The IR extension and HDMI loop-out functionality add valuable control options for the end-user, making it an all-in-one solution for modern AV distribution needs.
