Lindy 70m Cat.6 4 Port HDMI & IR Splitter Extender

The Lindy 70m Cat.6 4 Port HDMI & IR Splitter Extender is a professional plug-and-play solution designed to extend an HDMI signal up to 70m and distribute it to four remote displays via low-cost Cat.6 UUTP cable (not included). Ideal for AV and digital signage, this advanced splitter extender also supports IR pass-through, enabling remote control of source devices.

Supporting resolutions up to 4K30 (3840x2160@30Hz 4:4:4 8bit) and Full HD 1080p 3D, this solution is perfect for a wide range of applications, including business, education, retail, healthcare, and home AV environments. With its slim design, integrated mounting brackets, and Power over Cable (PoC) functionality, it ensures simple, reliable installation even in restricted spaces.

Key Features

• Extends and distributes HDMI & IR signals to 4 displays at up to 70m
• Supports resolutions up to 3840x2160@30Hz 4:4:4 8bit, including Full HD 1080p 3D
• Integrated HDMI loop-through for local monitoring or cascading (up to 12 displays)
• EDID emulation with 9 preset modes and cloning functionality
• Power over Cable (PoC) – single power supply required for full installation
• Reliable metal housing with slim design and mounting brackets for easy installation
• Backed by a 2-year warranty

Applications

• Digital signage in retail and hospitality
• Educational environments with multiple classroom displays
• Corporate boardrooms and business installations
• Healthcare and public information systems
• Home AV installations requiring multiple zones

Technical Specifications

• AV Interface: HDMI 1.4
• Supported Bandwidth: 10.2Gbps
• Maximum Distance: 70m (1080p@60Hz), 40m (4K30)
• Maximum Resolution: 3840x2160@30Hz 4:4:4 8bit
• HDCP Support: 1.4
• EDID Support: Pass-through, Preset, Cloning
• Supported Audio: Up to 7.1 pass-through
• IR Pass-through: 20–60kHz
• Transmission Medium: 1 x Cat.6 UUTP (per receiver)
• Special Features: HDMI loop-through, PoC (Power over Cable)

Connectors

• Transmitter Input: HDMI (Female)
• Transmitter Outputs: 4 x RJ45 (Female), HDMI (Female), IR (Female)
• Receiver Input: RJ45 (Female), IR (Female)
• Receiver Output: HDMI (Female)
• Power: 12VDC 2.5A via secure DC socket

Physical Properties

• Transmitter Dimensions: 210 x 83 x 17mm
• Receiver Dimensions: 79 x 68 x 17mm (per unit)
• Housing Material: Metal
• Net Weight: Transmitter 0.443kg, Receiver 0.131kg (per unit)
• Operating Temperature: 0°C – 40°C
• Colour: Black

Package Contents

• Splitter Transmitter Unit
• 4 x Receiver Units
• IR Emitter Cable
• 4 x IR Receiver Cables
• 2 x Mounting Brackets with Screws
• Multi-Country Power Supply (EU, UK, US & AUS)
• User Manual

Product Compliance

Certified CE, UKCA, FCC, RoHS & REACH.

Download

• User Manual for CAT6 4 Port HDMI & IR Splitter Extender, 50m
• Data Sheet for 38155 70m CAT6 4 Port HDMI & IR Splitter Extender
