Lindy 4x4 USB 3.2 Gen 1 Matrix Switch

The Lindy USB 3.2 Gen 1 Matrix Switch allows up to four USB devices to be shared between up to four host computers in a highly flexible way. Users can switch connections via the front panel buttons, an intuitive web-based GUI, or through RS-232 commands. With support for USB 3.2 Gen 1 SuperSpeed transfer rates of up to 5Gbps, as well as backwards compatibility with USB 2.0 and 1.1, this device is an ideal solution for offices, conference rooms, KVM setups, and industrial applications.

Key Features

• 4x4 Matrix Switching – share up to 4 USB devices with up to 4 host systems
• Multiple control options – switch via panel buttons, web GUI, or RS-232 commands
• Preset configurations – save up to 8 presets for faster operation
• Flexible labelling – rename hosts and devices for smoother management
• High-speed transfer – supports USB 3.2 Gen 1 at 5Gbps, backwards compatible with USB 2.0/1.1
• Device charging support – each USB Type A port supplies up to 900mA
• Plug & Play – no software required
• 2-year warranty for added peace of mind

Compatibility

USB 3.0, USB 3.1, and USB 3.2 devices are fully inter-compatible when using either a Type A or Type C host interface:

• USB 3.0 / 3.1 Gen 1 / 3.2 Gen 1: up to 5Gbps transfer rate
• USB 3.1 Gen 2 / 3.2 Gen 2: up to 10Gbps transfer rate

Applications

This professional-grade USB matrix switch is suitable for a wide range of uses, including:

• Sharing printers, storage devices, or webcams across multiple PCs or Macs
• Conference room presentation systems
• KVM applications
• Industrial and IT environments requiring reliable USB switching

Package Contents

• 1 x Lindy 4x4 USB 3.2 Gen 1 Matrix Switch
• 4 x USB 3.2 Gen 1 Type A-B Cables (1.2m)
• Multi-country Power Supply (UK, EU, US & AUS)
• Lindy User Manual

Technical Specifications

• USB Standard: USB 3.2 Gen 1 (5Gbps)
• Chipset: AT32F437 + VL817
• Power Delivery: 900mA per USB Type A port
• Inputs: 4 x USB 3.0 Type B (Female)
• Outputs: 4 x USB Type A (Female)
• Control Ports: RJ-45 (Female), RS-232 3-Pin Terminal Block
• Power Input: 12V 3A, 5.5/2.5mm
• Housing: Metal, black finish
• Dimensions: 221 x 105 x 26mm
• Weight: Net 1.15kg, Gross 1.45kg
• Operating Temperature: 0°C – 40°C
• Compliance: CE, FCC, RoHS, REACH, California Proposition 65

Download

• User Manual for 4x4 USB 3.2 Gen 1 Matrix Switch

Why Choose Lindy?

Lindy is a trusted name in professional connectivity solutions, offering innovative, reliable, and high-performance products. The Lindy 4x4 USB Matrix Switch is built for seamless multi-device management, ensuring efficient workflows in professional AV, IT, and office environments.
