Lindy 43155 5M Usb 3.0 Active Extension Cable, Usb Type A Male / Female

Note: Technology Products May Be Subject To Additional Fraud Checks By The Mega Team

The Lindy USB 3.0 Active Extension Cable uses built-in active electronics to extend the cable length of a USB 3.0 device by an additional 5m whilst continuing to support data transfer rates of up to 5Gbps.

With its USB A male and USB A female connector it allows Type A devices such as storage devices, webcams and other Type A devices to be connected at longer distances to PCs, laptops and tablets, while also ensuring flexible positioning. Up to 2 extension cables can be chained together.

The Lindy USB 3.0 Active Extension Cable is compatible with all USB Type A equipped computers.

It is certified by Google to provide a long distance active connection between the ASUS Chromebox and USB camera in a Google Hangouts Meet hardware installation, perfect for use in boardrooms and other video conferencing scenarios.

• 5 metre USB 3.0 Active Extension Repeater Lead
• Supports transfer rates up to 5Gbps
• For even greater distances simply connect 2 cables in series
• Plug & Play
• 2 year warranty

Package Contents

• USB 3.0 Active Extension 5m

TECHNICAL INFORMATION:

Connectors

• Connector A: USB Type A Male
• Connector B: USB Type A Female
• Power: -
• Housing Material: Plastic
• Connector Plating: Gold 3µ
• Pin Construction: Brass
• Pin Plating: Gold 15µ
• Dimensions (approx.) WxDxH:
  - USB A Male: 16x48x6mm (0.63x1.89x0.24in)
  - USB A Female: 24x46x12mm (0.94x1.81x0.47in)

Cable Construction

• Length: 5m (16.4ft)
• Standard: USB 3.1 Gen 1 / 3.0
• Colour: Black
• Type: Round
• Jacket Diameter: 5.5mm (0.22in)
• Jacket Material: Matt PVC
• Conductor Material: Tinned Copper
• Conductor Gauge: 28AWG+24AWG
• Shielding: AL Mylar

Specifications

• Supported Bandwidth: 5 Gbps
• Nominal Attenuation:
• 1.5dB/2M@0.1GHz
• 5.0dB/2M@1.25GHz
• 7.5dB/2M@2.5GHz
• 25dB/2M@7.5GHz
• Minimum Bend Radius: 55mm (2.17in)
• Maximum Tensile Load: 1500PSI min
• Operating Temperature: 0°C - 60°C (32°F - 140°F)
• Storage Temperature: 0°C - 70°C (32°F - 158°F)
• Transmission Medium: Twisted Pair
• Transmission Technology: USB 3.1 Gen 1 / 3.0

Miscellaneous

• Packaging Type: Blister
• Packaging Dimensions: 237x138x60mm (9.33x5.43x2.36in)
• Net Weight: 0.22kg (0.49lb)
• Gross Weight: 0.289kg (0.52lb)
• Warranty (Years): 2
• Certificated: CE, FCC, RoHS & REACH

DOWNLOAD:

• Datasheet for 43155 5m USB 3.0 Active Extension Cable (pdf) [Size: 146.52K]
