Lindy 38146 Hdmi To Displayport Uhd 4K Converter

Note: Technology Products May Be Subject To Additional Fraud Checks By The Mega Team

The Lindy HDMI 1.4 to DisplayPort 1.1 Converter is ideal for connecting an HDMI equipped source such as a PC, laptop or Blu-ray player to a DisplayPort monitor. It supports video resolutions up to Ultra HD 4K as well as 7.1 channel surround audio.

The converter can also be used to add another display to extend the available desktop workspace and increase productivity. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug & Play installation.

• Converts an HDMI input into a DisplayPort signal
• Supports resolutions up to 3840x2160@30Hz
• Supports 7.1 channel surround audio
• Quick and simple Plug & Play installation
• 2 year warranty

Package Contents:

• 8 Port Gigabit Ethernet Switch
• Multi-country PSU 5V 2.6Amp
• User manual

TECHNICAL INFORMATION:

Specifications

• AV Interface: HDMI to DisplayPort
• Interface Standard: HDMI 1.4 / DisplayPort 1.1
• Supported Bandwidth: 10.2Gbps
• Maximum Input Resolution: 3840x2160@30Hz 4:4:4 8bit
• Maximum Output Resolution: 3840x2160@30Hz 4:4:4 8bit
• Chipset: STDP2600
• HDCP Support: DPCP 1.3
• Supported Audio: Supports 7.1 LPCM digital audio up to 192kHz 24bit
• Separate Audio Ports: -
• Special Features: -

Connectors

• Input: HDMI Type A Female
• Output: DisplayPort Male

Physical Properties

• Dimensions (approx.) WxDxH:
• 40x45x15mm (1.57x1.77x0.59in)
• 20.5x16.5x3.5mm (0.81x0.65x0.14in) / DP
• Cable Length: 10cm
• Housing Material: PVC
• Jacket Material: PVC
• Minimum Bend Radius: -
• Net Weight: 0.028kg (0.06lb)
• Operating Temperature: -20°C - 85°C (-4°F - 185°F)
• Storage Temperature: -20°C - 85°C (-4°F - 185°F)
• Humidity: 20 - 95% RH (non-condensing)
• Colour: White

Miscellaneous

• Packaging Type: Polybag
• Packaging Dimensions: 160x160x20mm (6.3x6.3x0.79in)
• Gross Weight: 0.032kg (0.07lb)
• Warranty (Years): 2
• Certificated: CE, FCC, RoHS & REACH

DOWNLOAD:

• User Manual for HDMI to DisplayPort Converter (pdf) [Size: 89.65K]
• Datasheet for 38146 HDMI to DisplayPort UHD 4K Converter (pdf) [Size: 137.79K]
