Lindy USB 3.2 Gen 1 Cat.6A Extender

The Lindy USB 3.2 Gen 1 Cat.6A Extender allows you to extend the distance between USB peripheral devices and your host computer by up to 100 metres using a standard Cat.6A or higher network cable (not included). Designed for professional and industrial environments, this high-performance extender supports multiple USB signals including control, bulk, interrupt and isochronous data transfer, ensuring reliable and fast communication over long distances.

Key Features

• Extend 4 USB 3.2 Gen 1 ports up to 100m using Cat.6A network cable
• Supports USB 3.2 Gen 1 (5Gbps), backwards compatible with USB 2.0/1.1
• Power over Cable (PoC) – only one power supply needed at either transmitter or receiver
• Two ports provide up to 1.5A each, two ports up to 1A each for powering connected devices
• RS232 and FSYNC pass-through for industrial camera and control applications
• Robust metal housing with mounting brackets for secure installation
• Plug & Play – no driver installation required
• 2-year warranty

Professional-Grade Performance

This extender utilises the globally recognised HDBaseT standard for reliable transmission of high-speed data, power and control signals. For maximum performance over long distances, use HDBaseT-certified Cat.6A cables. The screw-type DC jack ensures a secure power connection – ideal for installations where accidental disconnection could cause downtime.

Technical Specifications

• USB Standard: USB 3.2 Gen 1
• Bandwidth: 5Gbps
• Maximum Distance: 100m with Cat.6A, 40m with Cat.6
• Transmission Medium: Cat.6A or higher network cable
• Chipset: VS6320
• Special Features: Power over Cable, FSYNC, RS232, control, bulk, interrupt, isochronous data
• Transmitter Input: USB 3.0 Type B (Female)
• Receiver Output: 4 × USB Type A (Female)
• Control Ports: RS-232 4-Pin Terminal Block
• Power: 24VDC 2A via 5.5/2.1mm DC socket
• Dimensions: 100 × 85 × 30mm (each unit)
• Housing: Metal
• Operating Temperature: 0°C – 40°C
• Colour: Black
• Certifications: CE, UKCA, FCC, RoHS, REACH, CP65

Applications

• Industrial camera control and monitoring
• Remote workstations in offices, factories or laboratories
• Conference rooms and AV control setups
• Secure server room device access

Package Contents

• Transmitter unit
• Receiver unit
• 1m USB 3.2 Gen 1 Type A Male to B Male cable
• 2 × 4-Pin Terminal Block
• Multi-Country Power Supply (EU, UK, US & AUS)
• Mounting brackets & screws
• Lindy user manual

Downloads

• User Manual for 100m USB 3.2 Gen 1 CAT6A HDBaseT Extender

Why Choose the Lindy USB 3.2 Gen 1 Cat.6A Extender?

Whether you’re installing devices in hard-to-reach areas or creating a professional AV and control setup, the Lindy USB 3.2 Gen 1 Cat.6A Extender provides the distance, speed and reliability you need – all with the simplicity of Plug & Play setup.
