Lindy Black Line 8K60Hz HDMI 2.1 Cable

Part of Lindy’s Lines cable connectivity concept, the Black Line 8K60Hz HDMI cable delivers a fully featured, entry‑level high‑resolution connection that’s ideal for home and small office AV setups. With support for 48Gbps bandwidth, 8K (7680×4320) at 60Hz and 4K (3840×2160) at 120Hz, plus multi‑channel immersive audio formats, it ensures crisp video and rich, reliable sound.

Key Features

• Entry‑level HDMI 2.1 cable for home and small office applications
• Supports UHD up to 7680×4320@60Hz (4:4:4, 10‑bit) and 3840×2160@120Hz
• 48Gbps bandwidth (up to 7.5m cable length)
• Triple‑shielded construction; corrosion‑resistant copper coated steel conductors
• Robust PVC housing, nickel connectors and gold‑flashed contacts for signal integrity
• Audio support: 32‑channel, Dolby® TrueHD, DTS‑HD Master Audio, Dolby Atmos, DTS:X
• HDMI features: 3D, HEC, ARC, eARC, CEC
• 10‑year warranty

Technical Specifications

• Connectors: HDMI Type A Male to HDMI Type A Male
• Housing Material: PVC
• Connector Plating: Nickel
• Pin Construction: Copper Alloy
• Pin Plating: Gold‑plated (gold‑flashed contacts)
• Connector Dimensions (W×D×H): 20 × 34.2 × 10.9mm (0.79 × 1.35 × 0.43in)

• Cable Standard: Ultra High Speed HDMI
• Colour: Black
• Type: Round
• Jacket Material / Ø: PVC / 6mm (0.24in)
• Conductor Material: Copper Coated Steel
• Conductor Gauge: 30AWG
• Shielding: Aluminium foil (triple‑shielded design)

• Supported Bandwidth: 48Gbps
• Maximum Resolution: 7680×4320@60Hz, 4:4:4, 10‑bit
• Nominal Attenuation: 3.5GHz > −5.5dB (HBR1); 2.7GHz > −8.5dB (HBR2); 4.05GHz > −11.0dB (HBR3)
• Minimum Bend Radius: 70mm
• Operating Temperature: −10°C to 80°C (14°F to 176°F)
• Storage Temperature: −20°C to 85°C (−4°F to 185°F)

• Packaging: Polybag (individual)
• Compliance: RoHS & REACH, UL
• Warranty: 10 years

Applications

• Connecting 8K/4K sources (PCs, consoles, streamers) to TVs, monitors, AV receivers and projectors
• High‑frame‑rate gaming at 4K120Hz and high‑detail video at 8K60Hz
• Home office and small meeting room displays requiring reliable UHD performance

FAQs

Is this cable backwards compatible?
Yes. It works with 4K60/30, 1080p and lower resolutions while maintaining excellent signal integrity.

Do I need HDMI 2.1 devices to get 8K60 or 4K120?
Yes. To use 8K60 or 4K120 features, both your source and display (and any in‑line devices) must support HDMI 2.1.

What is the maximum length for full 48Gbps support?
This Black Line cable supports the full 48Gbps bandwidth in lengths up to 7.5m.

Downloads

• Data Sheet: 8K60Hz HDMI Cable, Black Line
