Orange Panaro MAX505STR open, grey cubed foam in the base and convoluted foam in the black-edged lid
Orange MAX505TR trolley case closed with the black telescopic handle extended above the carry handle
Back of the orange MAX505 trolley case with the retracted black handle frame and two wheels
Black pressure release valve labelled AUTO PRESSURE RELEASE on the orange MAX case wall
Close-up of a closed black MAX latch joining the orange lid to the base
Orange Panaro MAX505STR open, grey cubed foam in the base and convoluted foam in the black-edged lid
Orange MAX505TR trolley case closed with the black telescopic handle extended above the carry handle
Back of the orange MAX505 trolley case with the retracted black handle frame and two wheels
Black pressure release valve labelled AUTO PRESSURE RELEASE on the orange MAX case wall
Close-up of a closed black MAX latch joining the orange lid to the base
Orange Panaro MAX505STR open, grey cubed foam in the base and convoluted foam in the black-edged lid
Orange MAX505TR trolley case closed with the black telescopic handle extended above the carry handle
Back of the orange MAX505 trolley case with the retracted black handle frame and two wheels
Black pressure release valve labelled AUTO PRESSURE RELEASE on the orange MAX case wall
Close-up of a closed black MAX latch joining the orange lid to the base
Panaro

Panaro MAX505STR Waterproof Case with Cubed Foam and Trolley Orange

$513.70
$513.70
RRP $550.43
Or 4 payments of $128.43 with
Add items to a quote for bulk pricing, approvals, or purchase orders.

SKU: PMMAX505STR-ORANGE

Orange Wheeled Case With Cubed Foam

The Panaro MAX505STR in orange is a high-visibility trolley case with pick and pluck foam, so a response kit can be wheeled in and spotted across a busy site.

The orange shell is simple to pick out in a crowded staging area, on a wharf or in the back of a response vehicle. It pulls on wheels with a telescopic handle, reaching 970 mm with the handle up, and measures 555 x 445 x 258 mm closed according to Panaro's drawing. Its 500 x 350 x 194 mm interior takes Panaro's cubed foam, two 55 mm layers resting on a 20 mm pad, with 50 mm of convoluted foam in the lid.

Panaro give 5.50 kg for this configuration. The STR page links Panaro's MIL-STD-810H report, and the STR datasheet marks IP67, STANAG 4280 and DEF STAN 81-41; ATA 300 appears only on the non-wheeled models. Nylon latches, a pressure release valve and padlock holes are standard. Made in Italy.

Browse medical and first aid carry cases, the Panaro collection and first aid cases.

Often ordered together

  • Hi-vis orange with a pull-along trolley
  • Two 55 mm cube layers to pluck to shape
  • Closed size 555 x 445 x 258 mm per Panaro
  • 5.50 kg, per Panaro
  • Pressure valve and padlock holes
  • Datasheet shows IP67; MIL-STD-810H report linked
  • Event medical and first responder kits
  • Marine safety electronics moved along jetties
  • Emergency communications sets
  • Site safety monitoring equipment
  • Search and rescue drones

Shipping

Shipping is kept simple with flat rates for selected areas and free shipping where applicable. Large, bulky, rural or out-of-area orders may require additional freight, and our team will contact you if this applies. For a more specific estimate, simply add this product to a quote or visit our shipping page.

Delivery Times

Melbourne, Sydney, Brisbane, Adelaide — 1 to 3 business days
Perth — 1 to 5 business days
Regional & Outer Areas — 3 to 7 business days

Returns

If you have questions about returns, please contact us or visit our returns page for full details.

Specifications

Brand: Panaro MAX Cases, made in Italy per Panaro

MPN: MAX505STR

Mega Code: PMMAX505STR-ORANGE

Colour: Orange

Configuration: STR, cubed foam with trolley

External Dimensions: 555 x 445 x 258 mm (page and 2D drawing)

Internal Dimensions: 500 x 350 x 194 mm

Lid + Base Depth: 58 + 136 mm

Capacity: 33.95 L

Weight: 5.50 kg, per Panaro

Materials: Polypropylene shell, nylon latches, polymer O-ring, metal and plastic trolley, stainless steel wheel pins, polyurethane foam

Height With Handle Extended: 970 mm (Panaro drawing)

Foam (Panaro sheet): 20 mm base, 2 x 55 mm cubed layers, 50 mm convoluted lid

Test Standards Listed by Panaro: MIL-STD-810H report on the page; datasheet also shows IP67, STANAG 4280, DEF STAN 81-41 (no ATA 300)

Pack Size: 1 case, sold each

EAN: 8011236505179

Downloads

Primary Distribution Centre

Factory 5, 12 Greenway Drive
Tweed Heads South NSW 2486

ABN 18 634 002 609

Get directionsContact us

FAQs

It combines the wheels and handle of the STR with a colour that is easy to find. Inside it is the same foam as the black version.
Panaro's TR drawing shows 970 mm overall with the handle fully up.
The STR page links the MIL-STD-810H report. The STR and HDSTR datasheet, also attached, shows IP67, STANAG 4280 and DEF STAN 81-41.
Panaro describe the TR as a case equipped with wheels and an extendable handle. They do not describe it as removable, so treat it as fitted.
