Rapidline Halo Plus return frame in black satin powdercoat for round leg height adjustable workstations. Supplied product image for model HP-RF BL.
Rapidline Height Adjustable Return Frame Only Black for Halo Plus Workstation
Rapidline Halo Plus return frame in black satin powdercoat for round leg height adjustable workstations. Supplied product image for model HP-RF BL.
Rapidline Height Adjustable Return Frame Only Black for Halo Plus Workstation
Rapidline Halo Plus return frame in black satin powdercoat for round leg height adjustable workstations. Supplied product image for model HP-RF BL.
Rapidline Height Adjustable Return Frame Only Black for Halo Plus Workstation
Rapidline

Rapidline Height Adjustable Return Frame Only Black for Halo Plus Workstation

Regular price
$580.23
Sale price
$580.23
Regular price
RRP $640.31
Or 4 payments of $145.06 with

SKU: FXHP-RF BL

MPN: HP-RF BL

The Second Leg of a Corner

This is the electric height adjustable return frame from the Halo Plus range, which drives the second leg of a corner workstation in step with the main frame, finished in black satin powdercoat.

A corner top needs support under both legs, and both have to rise together or the surface racks. This is the return frame that ships under the complete Halo Plus corner workstations. It telescopes from 1040mm to 2150mm and suits rectangular return tops and radial one piece corner tops with an overall return edge of 1450mm to 2150mm.

It carries the same controller as the main frame, with three pre-set positions, a keypad safety lock, and anti-collision and anti-tilt. Rapidline publishes a lifting capacity of 160kg for the return frame, above the 120kg of the single sided frame, on a 500mm foot.

It belongs to the Halo Plus range, which is listed complete as the single sided workstation and as the back to back version. The rest of the range, including the corner desks and the other parts, sits in office furniture.

  • Rapidline Halo Plus return frame in black satin powdercoat
  • 70mm diameter round columns, matching the complete Halo Plus workstations
  • Digital control panel with three pre-set positions, LED display, keypad lock and reminder alarm
  • Anti-collision and anti-tilt, travel of 595mm to 1245mm
  • Telescopic frame suiting tops from 1040mm to 2150mm W
  • Published lifting capacity of 160kg
  • Ten year Rapidline warranty
  • Building a corner workstation on customer supplied tops
  • Adding a return to an existing Halo Plus single sided frame
  • Radial one piece corner tops needing a driven second leg
  • Refits that keep an existing corner worktop

Shipping

Shipping is kept simple with flat rates for selected areas and free shipping where applicable. Large, bulky, rural or out-of-area orders may require additional freight, and our team will contact you if this applies. For a more specific estimate, simply add this product to a quote or visit our shipping page.

Delivery Times

Melbourne, Sydney, Brisbane, Adelaide — 1 to 3 business days
Perth — 1 to 5 business days
Regional & Outer Areas — 3 to 7 business days

Returns

If you have questions about returns, please contact us or visit our returns page for full details.

Specifications

Brand: Rapidline

Range: Halo Plus

Model: HP-RF BL

Mega Code: FXHP-RF BL

EAN: 9347414043393

Type: Return frame, black satin powdercoat

Size: 1040mm W x 500mm D x 595mm H

Columns: 70mm diameter round columns

Height Range: 595mm to 1245mm, dual motor at up to 38mm per second

Suits Tops: 1040mm to 2150mm W

Lifting Capacity: 160kg

Product Weight: 19.0kg

Carton Dimensions: 1050mm W x 260mm D x 210mm H

Warranty: 10 years, AFRDI certified with SAA and C Tick

Unit: Each

FAQs

It is made for the Rapidline Halo Plus range and is the same part that ships with the complete workstations. Halo Plus uses 70mm diameter round columns, so parts are not interchangeable with the rectangular Boost Plus frame - check the range before ordering.
What is in the carton is set out in the specifications above, so the count can be checked before ordering rather than after it arrives. Ask us if you are unsure how many a particular desk run needs.
Rapidline warrants this part for ten years, the same term as the complete Halo Plus desks. That keeps one warranty story across a fitout that mixes complete workstations and frame only builds.
Yes. It is a separate line rather than an option on the desk listing, so add it alongside the workstations. If you tell us the desk layout we will work out how many you need.
